TB20-C, Bus Coupler CANopen® Slave
(0)
Stok Kodu
:
600-160-1AA11
Ürün Bilgisi
CANopen® protocol as defined in DSP301 and DS401
• Baud rates of 50 kbps to 1 Mbps
• 24 TPDOs / 24 RPDOs
• One SDO server
• Heartbeat producer
• Two heartbeat consumers
• Node guarding
• SYNC object
• Storable parameter configuration
• Up to 64 peripheral modules
• Modules can be replaced during operation (hot-plug)
• 24 VDC power supply
• Integrated power supply unit for powering peripheral modules (2.5 A)
• Supplies the system’s I/O voltage (24 VDC)
• DIP switch for setting the node ID and baud rate; can be covered
• 5 LEDs, two of them bi-color
• USB device port for online diagnostics, configuring parameters, setup, and firmware updates with "TB20 ToolBox"
• TB20 ToolBox simulation for setting up the I/O system without a higher-level controller in order to test the system`s
operation (I/O check)
