TB20-C, Bus Coupler DeviceNet™
(0)
Stok Kodu
:
600-165-1AA11
Ürün Bilgisi
• Group 2 Server
• UCMM capable
• Features Polled, Bit-Strobe, COS/Cyclic connections
• Supports Offline Connection Set, Device Heartbeat and Device Shutdown message• Software and hardware (via DIP switch) settable MAC ID and Baud Rate
• Supports 125, 250 and 500 kbits/s
• A maximum of 64 modules
• 1024 bytes of input data / 1024 bytes of output data
• 120 bytes of parameter data per module
• With the help of "TB20 ToolBox", modules can be freely configured
• Configuration with Allen-Bradley RSNetWorxTM using explicit messaging service possible
• The coupler`s state can be read using explicit messaging service
• Supports module diagnostics
• Supports hot-plugging
• 24 VDC power supply
• Features an Open Style Connector
• Integrated power supply unit for powering peripheral modules (2.5 A)
• Supplies the system’s I/O voltage (24 VDC)
• Six LEDs, four of them bi-color (three DeviceNet LEDs and one TB20 specific)
• USB device port for online diagnostics, configuring parameters, setup, and firmware updates with "TB20 ToolBox"
• Concealed "factory reset" switch for restoring the module to its factory settings
• TB20 ToolBox simulation for setting up the I/O system without a higher-level controller in order to test the system`s operation (I/O check)
