TB20-C, Bus Coupler EtherNet/IP
(0)
Stok Kodu
:
600-175-1AA11
Ürün Bilgisi
• Supports unicast and multicast CIP connections
• 511 bytes of input assembly data; 511 bytes of output assembly data
• TB20 ToolBox can be used for easy access to assembly sizes and to the structure of the image table within the
assemblies
• Up to 64 peripheral modules
• Modules can be replaced during operation (hot-plug)
• Implicit messaging (transport class 1)
• Explicit messaging (transport class 3)
• TCP watchdog
• IP address can be set relative to a base IP address by using a DIP switch that can be covered
• DHCP (can be selected using DIP switch)
• Integrated two-port switch with two RJ45 connectors
• Module process data is automatically assigned to the EtherNet/IP mapping
• 24 VDC power supply
• Integrated power supply unit for powering peripheral modules (2.5 A)
• Supplies the system’s I/O voltage (24 VDC)
• 9 LEDs, three of them bi-color
• USB device port for online diagnostics, configuring parameters, setup, and firmware updates with "TB20 ToolBox"
• TB20 ToolBox simulation for setting up the I/O system without a higher-level controller in order to test the system`s
operation (I/O check)
• Concealed "factory reset" switch for restoring the module to its factory settings
• 511 bytes of input assembly data; 511 bytes of output assembly data
• TB20 ToolBox can be used for easy access to assembly sizes and to the structure of the image table within the
assemblies
• Up to 64 peripheral modules
• Modules can be replaced during operation (hot-plug)
• Implicit messaging (transport class 1)
• Explicit messaging (transport class 3)
• TCP watchdog
• IP address can be set relative to a base IP address by using a DIP switch that can be covered
• DHCP (can be selected using DIP switch)
• Integrated two-port switch with two RJ45 connectors
• Module process data is automatically assigned to the EtherNet/IP mapping
• 24 VDC power supply
• Integrated power supply unit for powering peripheral modules (2.5 A)
• Supplies the system’s I/O voltage (24 VDC)
• 9 LEDs, three of them bi-color
• USB device port for online diagnostics, configuring parameters, setup, and firmware updates with "TB20 ToolBox"
• TB20 ToolBox simulation for setting up the I/O system without a higher-level controller in order to test the system`s
operation (I/O check)
• Concealed "factory reset" switch for restoring the module to its factory settings
