TB20-C, Bus Coupler PROFIBUS-DP Slave
(0)
Stok Kodu
:
600-151-1AA11
Ürün Bilgisi
• PROFIBUS DP slave as defined in EN 50170/IEC 61158
• Supports all PROFIBUS baud rates
• DP-V0 and DP-V1 support
• Up to 64 peripheral modules
• Modules can be replaced during operation (hot-plug)
• Up to 244 bytes of input data and 244 bytes of output data
• One class 1 master connection with 240 bytes of payload data
• Up to three class 2 master connections with 240 bytes of payload data (as a DP-V1 slave)
• Bit packing for 2-bit and 4-bit modules
• 24 VDC power supply
• I&M data
• Integrated power supply unit for powering peripheral modules (2.5 A)
• Supplies the system’s I/O voltage (24 VDC)
• DIP switch for setting the PROFIBUS address; can be covered
• 3 LEDs, two of them bi-color
• USB device port for online diagnostics, configuring parameters, setup, and firmware updates with "TB20 ToolBox"
• TB20 ToolBox simulation for setting up the I/O system without a higher-level controller in order to test the system`s
operation (I/O check)
